Rhino to Inventor Exporter

A data exchange plugin which creates Inventor Parts and Assemblies from Rhino Blocks.

No credit card required.

At a Glance

How to Export Rhino models to Inventor?

The Multi-CAD collaboration is facing multiple challenges. The BIMDeX Data Exchange Ecosystem through its proprietary BXF file format offers a simple yet intuitive solution for the Interoperability challenges.

Rhino to Inventor data Exporter/Converter is a simple way of data exchange through plug-in/add-on tool which creates native Inventor Parts (.ipt) and Assemblies (.iam) from Rhino blocks (.3dm)
Exports your Rhino model into a BXF file using BXF Exporter Plug-in. Which can be Imported in the Inventor platform using BXF Importer Plug-in.
There will be no loss in geometry or any other meta data, all the associated properties would be brought in and the RGB colors as well.
The tool supports various industry specific requirements like geometric simplification, parameter data exchange.
It comes with multilingual support (English, Spanish, French, German, Italian, etc.)

Supported Versions:

Rhino: 5.0, 6.0 & 7.0

Inventor: 2020 - 2024

How It Works

Rhino to Inventor Conversion Workflow

Rhino

3DM file Format

Export the Rhino Model to BXF file using the BXF Exporter for Rhino

BIMDeX

BXF file Format

BXF file would carry all the design data information of the model.

Inventor

IPT & IAM file Formats

Import the BXF file in Inventor using the BIMDeX Importer to obtain native Inventor Parts & Assemblies

Product Benefits Video

Product Brochure

How Is It Different?

Rhino to Inventor Conversion Features

Expose Rhino platform into the CAD environment with easy transfer of Rhino model to Inventor, other BIM and mechanical software. Control and safe data transfer.

Convert all Rhino Geometry

Convert all your Rhino geometries to native Inventor models and save the custom settings for ease of use.

Layer or Block Specific Export

Export based on your desired layers, block name or group name and group the geometry based on Layer Hierarchy or Layer Name or Object type.

Geometry Selection and Customization

Export models based on Internal Origin from Rhino and Include or Exclude Locked components, Hidden components, Duplicated Components, Attachment and Orphan geometries.

Better Geometry Conversion

Smoothen the edges for meshes and obtain non-triangulated solid geometry. Instantiate the blocks and maintain the hierarchy inside Inventor.

Parameters and Materials

Export models with parameter and material information (RGB colors) and maintain the same in Inventor.

Easy Operation

Make use of various features to simplify your models with the user-friendly interface combined with easy operation to assist novice and experienced designers alike.
