creo to revit Exporter
Creo to Revit data Exporter/Converter is a simple way of data exchange through plug-in/add-on tool which creates native Revit Families (.rfa) and projects (.rvt) from Creo Assemblies (.asm) and Parts (.prt), along with the metadata, heirarchy and categories.
At a Glance
How Creo models Imported in Revit?
How It Works
Creo to Revit Conversion Workflow
01
Creo
PRT & ASM file Formats
Export the Creo Model to BXF file by using BXF Exporter for Creo
02
BIMDeX
BXF file Format
BXF file would carry all the designed data information of the model.
03
Revit
RFA & RVT file Formats
To get a native Revit Families & projects file by import the BXF file in Revit using BFX Importer for Revit
How Is It Different?
Creo to Revit Conversion Features
Expose Creo platform into the BIM environment with easy transfer of Creo model to Revit through the BIMDeX customized and safe data exchange platform.
Part/Assembly To Family/Project
Convert all your Creo Assemblies (.asm) and Parts (.prt) to native Revit families (rfa) and projects (rvt).
Simplified Representation Export
Export based on your desired Simplified Representation in Creo to exchange only the necessary components.
Category Mapping
Creo parts and assemblies can be mapped to specific categories in Revit while importing.
Maintain Instances
BIMDeX Instantiates Creo Parts and Assemblies inside Revit for ease of editability and facilitates better BOQ generation
Model Hierarchy
Hierarchy of the Creo model will be maintained in Revit and users have an option to collapse/flatten the hierarchy based on the requirement. Creo Assemblies and Sub-Assemblies will be converted as Nested families in Revit.
Metadata Information
All the metadata information from Creo can be transferred to Revit and users have the option to make it as Shared parameters in Revit.
Import based on Coordinates
Users can both export and import the models based on the desired Coordinate system.
Option to choose Revit Templates
Users can import the model in any desired Custom Generic Revit templates based on the requirement.
